7602012-TVP
Axial angular contact ball bearing
Axial angular contact ball bearing 7602..-TVP, single direction, no screw mounting
Replaces
7602012TVP
Main Dimensions & Performance Data
| d | 12 mm | Bore diameter |
0 mm | Bore diameter upper tolerance | |
-0,004 mm | Bore diameter lower tolerance | |
| D | 32 mm | Outside diameter |
0 mm | Outside diameter upper tolerance | |
-0,006 mm | Outside diameter lower tolerance | |
| B | 10 mm | Width |
0 mm | Width upper tolerance | |
-0,08 mm | Width lower tolerance | |
| Ca | 12.200 N | Basic dynamic load rating, axial |
| C0a | 20.700 N | Basic static load rating, axial |
| Cua | 940 N | Fatigue load limit, axial |
| nG Grease | 14.100 1/min | Limiting speed for grease lubrication |
| nϑ | 8.000 1/min | Thermally safe operating speed |
| ≈m | 42 g | Weight |
Mounting dimensions
| Da | 27 mm | Diameter of housing |
| Da | H12 | Diameter of housing clearance |
| da | 17 mm | Diameter shaft |
| da | h12 | Diameter shaft clearance |
Dimensions
| rmin | 0,6 mm | Minimum chamfer dimension |
| r1 min | 0,6 mm | Minimum chamfer dimension |
| a | 24 mm | Distance between the apexes of the pressure cones |
| α | 60 ° | Contact angle |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 120 °C | Operating temperature max. |
Additional information
| MR | 0,015 Nm | Bearing frictional torque |
| caL | 476 N/µm | Rigidity axial |
2 µm | Axial runout | |
ZM12 | Recommended INA precision locknut for radial locking | |
| MA | 8 Nm | Tightening torque for the recommended INA precision locknut |
6.110 N | Required locknut force axial |
Operating conditions for bearing 7602012-TVP
In work for 7602012-TVP
CO₂e caused by friction during operation
Comprehensive information with immediate calculations of the CO2e emissions of our rotative products in various application scenarios.
Load
*MandatoryMotion Influences
*Mandatory Preset calculation parameters
Arcanol MULTI2
Greasenormal cleanliness
Contamination70°C
Operating Temperature20°C
Ambient Temperature Choose your calculations
Powered by Bearinx
Please add the remaining conditions.
CO₂e emissions
For Production info_outline
-
Rating life
Total Rating Life (Lh10)
-
Static safety (S0)
-
